Product Details:
Payment & Shipping Terms:
|
Type: | Cold Rolling Mill | Condition: | New |
---|---|---|---|
Voltage: | 380V-440V | Power: | 800 KW-2000KW-4500kw |
Dimension(L*W*H): | 150m*30m*6m | Warranty: | 1 Year |
Applicable Industries: | Machinery Repair Shops, Manufacturing Plant, Steel Wire Rod Production Line Rolling Mill | After-sales Service Provided: | Field Installation, Commissioning And Training, Video Technical Support, Online Support |
Weight: | 20t 50t 100t 500t | Product Name: | 2 Ribbed Cold Rolled Steel Mill Rolling Mill |
Raw Material: | Steel Billets | Application: | Making Rebar Steel Bar |
Item: | Large Capacity Rolling Mill | Usage: | Rebar Production Line Square Steel Billets Rebar Steel Rolling Mill |
Rolling Type: | Cold Rolling Mill | Definition: | Rebar Steel Bar Hot Rolling Mill |
Main Function: | Making Rebar Steel Bar | Final Product: | Rebar Steel Bar |
Main Machine: | Cold Rolling Mill | Port: | Qingdao , Tianjin, Shanghai , Guangzhou |
1.Rebar rolling mill description
The rebar rolling mill can make Φ8-30 mm rebar (according to the clients’requirements) for construction by steel billets or round steel bar. If the material is scrap steel ,the rebar production line shall be equipped the melting furnace and the casting machine. We provide the design of the whole production line , and turnkey project is provided .
Technical parameters | ||||||
Item | Unit | FF300×4 | FF250×6 | FF250×2 | FF220×2 | |
Roll diameter | mm | Φ280-Φ330 | Φ230-Φ280 | Φ230-Φ380 | Φ200-Φ240 | |
Roll working length | mm | 700 | 500 | 500 | 350 | |
Main motor | Power | KW | 630 | 800 | 240 | 185 |
Rotating speed | FPm | 590 | 590 | 738 | 738 | |
Distribution box | Module | mn | 12 | 10 | 10 | 8 |
Center distance | mm | 1350 | 1250 | 1250 | 1200 | |
Tooth width | mm | 615 | 500 | 450 | 400 | |
Gear box | Module | mn | 12 | 10 | 10 | 8 |
Center distance | mm | 310 | 260 | 260 | 220 | |
Tooth width | mm | 604 | 550 | 450 | 500 | |
Driving type | Cardan shaft | Cardan shaft | Cardan shaft | Cardan shaft |
2.Final products: each size of rebar
The rebar products are like the pictures showed
3.Kinds of rolling mill
Rolling mills are the main products in our company ,there are not only rolling mill for rebar ,but also for steel plate,steel angle l ,flat bar, square bar, U bar and other section steel . At the same time , the rolling mills for copper ,aluminuim or other metal products are also provided.
We also offer accessories of rolling mill: roller bed, cooling bed, hot saw, steel pusher,straightening machine, elevator platform, flying shear, and old line retrofitting.
4.Services we can provide
a. Design the rolling mills and producitonline according to the customer’s needs.
b. Produce the rolling mills and other accessory equipments in the productionline.
c. Provide installation and commissioning at site
d. Provide technical guidance and training
e. Provide life long after-sale service
f. Provide accessories in the life time of the rolling mill and other equipments from our company.
5. Warranty time :1 year
6.Delivery time : 60 days after we receive the deposit
7.Payment terms: 30% deposit , 70% balance before shipment
8. Company profile:
Gongyi Hengxu Machinery Manufacture Co, Ltd is located at North Part of Zijing Road of Gongyi City,Henan Province. We are a leading professional supplier of R&D, produce, sales and after-sale service for rolling mill. Our company specializes in producing rolling mill, hot rolling mill, cold rolling mill, section bar rolling mill
We passed ISo 9001: 2008 certification, AAA Trustworthiness Enterprise, Bureau Veritas Certification.
We have been selling our products to over 20 countries:UK, France, Kazakhstan, Russia, Malaysia, Vietnam, Burma, Bengal, Uzbekistan, Sudan, Zimbabwe, Zambia, Algeria, Egypt etc.
Bearing the enterprise aim of " Better quality, Better service", we adhere to win-win principle with customers. Welcome customers at home and abroad to investigate and negotiate for cooperation.
