Product Details:
Payment & Shipping Terms:
|
Type: | Hot Rolling Mill | Condition: | New |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
Core Components: | PLC, Engine, Bearing, Gearbox, Motor | Voltage: | 380 |
Power: | 380KW | Dimension(L*W*H): | 30 M *10m |
Warranty: | 1 Year | Key Selling Points: | Long Service Life |
Showroom Location: | None | Applicable Industries: | Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction Works |
Product Name: | Steel Hot Rolling Mill Mini Steel Rolling Mill | Final Product: | Steel Rebar Round Bar |
Raw Material: | Steel Billet 60*60 70*70 Mm | Output: | 1-2 T/h |
Application: | Rebar Round Bar Rolling Mill Plant Factory | After Sales Service Provided: | Provide Technical Support |
Fuel: | Rolling Mill Worked By Electricity | Usage: | To Make Steel Rebar Round Bar |
Installation: | Provided | Item: | Rebar Round Bar Rolling Mill |
After-sales Service Provided: | Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
Local Service Location: | None | Weight: | About 35 T |
Port: | Qing Tao , Tianjin |
1. Produciton process
Melting furnace → Castiong machine → heating furnace→Φ280-3 Opentrain rolling mill → Cut-to length cutter→Cooling bed→Baler
The following parameters in the tabel are just for reference.
Technical parameters |
||||||
Item |
Unit |
FF300×4 |
FF250×6 |
FF250×2 |
FF230×2 |
|
Roll diameter |
mm |
Φ280-Φ330 |
Φ230-Φ280 |
Φ230-Φ380 |
Φ200-Φ240 |
|
Roll working length |
mm |
700 |
500 |
500 |
350 |
|
Main motor |
Power |
KW |
630 |
800 |
240 |
110 |
Rotating speed |
FPm |
590 |
590 |
738 |
738 |
|
Distribution box |
Module |
mn |
12 |
10 |
10 |
8 |
Center distance |
mm |
1350 |
1250 |
1250 |
1200 |
|
Tooth width |
mm |
615 |
500 |
450 |
400 |
|
Gear box |
Module |
mn |
12 |
10 |
10 |
8 |
Center distance |
mm |
310 |
260 |
260 |
220 |
|
Tooth width |
mm |
604 |
550 |
450 |
500 |
|
Driving type |
Cardan shaft |
Cardan shaft |
Cardan shaft |
Cardan shaft |
2. The final products of the rolling mill
3.Company profile
Gongyi Hengxu Machinery Manufacture Co, Ltd is a leading professional supplier of R&D, produce, sales and after-sale service for rolling mill. Our company specializes in producing rolling mill, hot rolling mill, cold rolling mill, section bar rolling mill.
We also offer accessories of rolling mill: roller bed, cooling bed, hot saw, steel pusher,straightening machine, elevator platform, flying shear, and old line retrofitting.
4.Certifications
We have implemented a strict and complete quality control system, which ensures that each prod-uct canmeet quality requirements of customers. Besides, all of our products have been strictly ins-pected before shipment. Our products have attained certification as follows;
“AAA grades trustworthiness enterprise of China”,
“Henan Province Product Quality Brand”,
“Henan Province Advanced Unit” .
"ISO9000 International Quality System Certification "
"license of import and export.certification“
5.Cooperation
We have been selling our products to over 20 countries:UK, France, Kazakhstan, Russia, Malaysia, Vietnam, Burma, Bengal, Uzbekistan, Sudan, Zimbabwe, Zambia, Algeria, Egypt etc.
