4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt small.img.alt

Large Image :  4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill Get Best Price

Product Details:
Place of Origin: Henan, China
Brand Name: Hengxu
Certification: ISO
Payment & Shipping Terms:
Price: $1,450,000.00/Sets 1-2 Sets
Packaging Details: Nude ,wooden box ,We will choose the suitable way to pack the equipments.<br>or packing the equipments according to the clients'requirements.
Supply Ability: 10 Set/Sets per Year
Detailed Product Description
Type: Cold Rolling Mill Condition: New
Video Outgoing-inspection: Provided Machinery Test Report: Provided
Marketing Type: New Product 2020 Warranty Of Core Components: 1 Year
Core Components: PLC, Engine, Bearing, Gearbox, Motor Voltage: 380
Power: 650 KW Dimension(L*W*H): 9 M * 20m
Warranty: 1 Year Key Selling Points: Long Service Life
Showroom Location: None Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction Works
Product Name: Aluminium Rolling Mill 4hi Cold Rolling Mill Alumnum Foil Rolling Mill Final Product: Aluminum Foil
Raw Material: Aluminum Ingots Output: 8-15 T/h
Application: Aluminum Cold Rolling Mill After Sales Service Provided: Provide Technical Support
Fuel: Aluminum Foil Rolling Mill Usage: To Make Aluminum Foil
Installation: Provided Item: Aluminum 4hi Cold Rolling Mill
After-sales Service Provided: Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: None Weight: About 280 T
Port: Qing Tao , Tianjin

  Aluminium rolling mill 4hi cold rolling mill alumnum foil rolling mill

 1. Produciton process

Melting furnace →Aluminum Castiong machine → Aluminum cold rolling mill

The following parameters in the tabel are just for reference.

Technical parameters

Item

Unit

FF300×4

FF250×6

FF250×2

FF230×2

Roll diameter

mm

Φ280-Φ330

Φ230-Φ280

Φ230-Φ380

Φ200-Φ240

Roll working length

mm

700

500

500

350

Main motor

Power

KW

630

800

240

110

Rotating speed

FPm

590

590

738

738

Distribution box

Module

mn

12

10

10

8

Center distance

mm

1350

1250

1250

1200

Tooth width

mm

615

500

450

400

Gear box

Module

mn

12

10

10

8

Center distance

mm

310

260

260

220

Tooth width

mm

604

550

450

500

Driving type



Cardan shaft

Cardan shaft

Cardan shaft

Cardan shaft



 2. The final products of the rolling mill

   4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

 4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

3.Company profile

Gongyi Hengxu Machinery Manufacture Co, Ltd is  a leading professional supplier of R&D, produce, sales and after-sale service for rolling mill . Our company specializes in producing rolling mill, hot rolling mill, cold rolling mill, section bar rolling mill, aluminum casting machine.

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill



4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

We also offer accessories of rolling mill: roller bed, cooling bed, hot saw, steel pusher,straightening machine, elevator platform, flying shear, and old line retrofitting.

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

 4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

4.Certifications

 We have implemented a strict and complete quality control system, which ensures that each prod-uct canmeet quality requirements of customers. Besides, all of our products have been strictly ins-pected before shipment. Our products have attained certification as follows;

“AAA grades trustworthiness enterprise of China”,

“Henan Province Product Quality Brand”,

“Henan Province Advanced Unit” .

"ISO9000 International Quality System Certification "

"license of import and export.certification“



4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill



5.Cooperation

We have been selling our products to over 20 countries:UK, France, Kazakhstan, Russia, Malaysia, Vietnam, Burma, Bengal, Uzbekistan, Sudan, Zimbabwe, Zambia, Algeria, Egypt etc.

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill

4 Hi Aluminum Foil Rolling Mill Cold Rolling Mill
